DS65K (0.154 sec/60° - 30.55 oz/in @6V)

DS65K (0.154 sec/60° - 30.55 oz/in @6V)
View detailed images (1)

DS65K
Details
SKU MKS-DS65K
Quantity in stock 733 item(s) available
Dead Band 0.001ms (Default)
Spline Size 5mm
Control System +Pulse Width Control
Working Frequence 1500μs / 333hz data: 850μs~2150μs
Operating Voltage 4.8 ~ 6.0 V DC Volts
Operating Temperature Range -10 to + 60 Degree C
Operating Speed (4.8V) 0.203 sec/60° degrees at no load
Operating Speed (6V) 0.154 sec/60° degrees at no load
Stall Torque (4.8V) 1.85 kg.cm (TBA oz/in)
Stall Torque (6V) 2.20 kg.cm (TBA oz/in)
Motor Type Coreless Motor
Potentiometer Drive Direct Drive
Driver Type FET
Bearing Type 2 Bearing
Gear Type 7075 Aluminium gear
Dimensions 22 X 8.5 X 15 mm (0.87 X 0.33 X 0.59 in)
Weight 6.5 g (0.23 oz)

Our price: $67.99
