HBL980 (0.036 sec/60° - 86.10 oz/in @7.2V)
View detailed images (2)
SKU
MKS-HBL980
Quantity in stock
454 item(s) available
Dead Band
0.0008ms (Default)
Spline Size
6mm 25 tooth
Control System
+Pulse Width Control
Working Frequence
760μs / 560hz
(RX) Required Pulse
3.5 ~ 7.2 Volt Peak to Peak Square Wave
Operating Voltage
4.0 ~ 7.2 V DC Volts
Operating Temperature Range
-10 to + 60 Degree C
Operating Speed (6V)
0.04 sec/60° degrees at no load
Operating Speed (8.4V)
0.030 sec/60° degrees at no load
Stall Torque (6V)
62.49 oz/in (4.5 kg.cm)
Stall Torque (8.4V)
86.10 oz/in (5.6 kg.cm)
Motor Type
Brushless Motor
Potentiometer Drive
Indirect Drive
Driver Type
FET
Bearing Type
Dual Ball Bearings
Gear Type
Titanium Gears
Programmable
NO
Connector Wire Length
24.0 cm (9.4 in)
Dimensions
40 x 20 x 40 mm ( 1.57x0.79x1.50 in)
Weight
70.29 g (2.48 oz)
Our price:
$
135.99
